Complete Electrical routing
Basics of qualify parts
Qualify Simple Clips
Orient Branch
Electrical Component Navigator
Importing and Exporting a Connection List
Basics of UGNX
MY UG NX crash course
Basics of sketch
The NX electrical routing course is designed to teach you the basics of electrical routing as it applies to the design of wiring and harness connectors you will cover the basic electrical routing teologies electrical design process parts parts teals and stocks upon completing of this course you will be ready to start designing your own wiring harness projects
A wire harness is a group of wires and cables that can be bundled together and are routed in various configurations to transfer electricity/information to and from various switches and devices.
The designer builds a master part file for a family of harnesses. By using a master part file, all of the lengths are deteed with allowances for movement and interferences. The master part file also keeps the proliferation of harnesses to a minimum. The wire harness is usually one of the last components to design because all the component location information must be compiled, established and assembled before you can define the scope of the harness. You need to know which connectors are used for each application and other components. You need to have knowledge of the movement or location of other non-electrical components to which you have to route wires through or around. Attachment points for securing the harness must also receive special consideration. Spacing clips or clamps too far apart can cause a rattle condition. Gravity also plays a part in securing the harness. Safety is the most important requirement. You can start to see why you need to gather all the information of the configuration before starting your design of the wire harness.
In this course you will be going to learn how electrical routing behaves when it is activated in uaphics NX application
you are going to learn how to qualify your parts how to qualify clips and much other things
To understand this course you must have a knowledge on any graphics application please check my uaphics NX basic crash course and complete that to understand this better
In this course you are going to learn how to create a form boards How to create a fixture pot how to keep create fitting port and how to move place.
Important connections and exporting connections for Electrical routing workbench
Different projects on electrical routing flying shape type project creating a linear paath paath operation overview stock of set point subdivide snt transform path connect path delete routing objects assign corner these are the few commands that we are going to learn in our electrical and wiring harness workbench
Designers, Electrical Eeers, Mechanical Eeers
